Common Arthropod Pests of Dry Beans in North Dakota

(E2023, June 2021)

This publication describes the common arthropod pests of dry bean in North Dakota. The following pests are included: aphids, grasshoppers, potato leafhoppers, foliage-feeding caterpillars (green cloverworm, painted lady butterfly), armyworms, cutworms, seed corn maggot and spider mites. The goal of this publication is to help pest managers with proper identification. A brief description and photograph of the immature and adult life stages is provided for each pest.

Lead Author
Lead Author:
Janet J. Knodel, Professor and Extension Entomologist
Other Authors

Patrick Beauzay, State Integrated Pest Management Coordinator and Research Specialist; Veronica Calles-Torrez, Post-doctoral Scientist

Available in print from the NDSU Distribution Center.,

Contact your county NDSU Extension office to request a printed copy.
NDSU staff can order copies online (login required).

Web only
Publication Sections

Black Bean Aphid

(Figure 1)

Nymph: Similar to adult but smaller, black body with slight reddish tint, always without wings.

Adult: Small, about 1/16 inch long, pear-shaped, black body with white and black legs, two cornicles (look like tailpipes) at posterior end, winged or wingless.

Important vectors of viral diseases.

black bean aphids
Figure 1. Black bean aphids (C. DiFonzo, Michigan State University)


Nymph (Figure 2): Resembles the adult, but smaller and without fully developed wings (wing pads only).

Adult (Figure 3): Size varies by species (1 to 1¾ inch long), brown to grayish-green, prominent head, large compound eyes, enlarged hind legs for jumping. Fully developed wings.

grasshopper nymph
Figure 2. Grasshopper nymph (P. Beauzay, NDSU)
grasshopper adult
Figure 3. Two-striped grasshopper adult. (J. Knodel, NDSU)

Potato Leafhopper

Nymph (Figure 4): Similar to adult, but smaller, greenish yellow
and wingless.

Adult (Figure 5): Less than 1/8 inch long, narrow, wedge-shaped, pale green body. Wings are translucent green and folded over the back at rest. Nymphs and adults jump or walk rapidly sideways when disturbed. Migrates into North Dakota each spring.

potato leafhopper nymph
Figure 4. Potato leafhopper nymph. (J. Knodel, NDSU)
potato leafhopper adult
Figure 5. Potato leafhopper adult. (S. Brown, University of Georgia, Bugwood.org)

​ Foliage Feeding Caterpillars ​

Green Cloverworm

Caterpillar or larva (Figure 6): Mature larva about 1¼ inches long. Pale green, with one long narrow white stripe on each side, three pairs of fleshy prolegs at the center part of the body and one pair of prolegs at the rear end. Moves in
a looping behavior.

Adult (Figure 7): Wingspan of 1 inch. Dark brown moth with spots. When moth rests, wings form a triangle. Migrates into North Dakota each spring.

green cloverworm larva
Figure 6. Green cloverworm larva. (J. Gavloski, Manitoba Agriculture, Food and Rural Initiatives)
green cloverworm adult
Figure 7. Green cloverworm adult. (J. Gavloski, Manitoba Agriculture, Food and Rural Initiatives)

Painted Lady Butterfly/Thistle Caterpillar

Caterpillar or larva (Figure 8): Mature larva about 1½ inches long. Brown to black with yellow striping along each side of the body and covered with branched spiny hairs, giving a prickly appearance. Webbed nest in curled leaves where they feed on foliage. Black pellets (frass) inside web.

Adult (Figure 9): Wing span of 2½ to 3½ inches. Forewings red-orange and brown with black and white spots. Hindwings orange-brown with four black “eye spots” along the edge. Feeds on flower nectar and aphid honeydew. Migrates into North Dakota each spring.

thistle caterpiller
Figure 8. Thistle caterpiller in webbed nest. (V. Calles-Torrez, NDSU)
painted lady butterfly
Figure 9. Painted lady butterfly. (P. Beauzay, NDSU)


Larva (Figure 10): Light tan to dark greenish-brown caterpillar with three longitudinal stripes (pale orange, white, brownish and/or black) on smooth and almost hairless body, about 1½ to 2 inches long when mature. Defoliates leaves/pods, usually in moist, shady areas where lodging is present.

Adult (Figure 11): Light brown moth with a conspicuous white spot about the size of a pinhead on each front wing, wingspan of 1½ inches.

armyworm larva
Figure 10. Armyworm larva. (P. Beauzay, NDSU)
armyworm adult
Figure 11. Armyworm adult. (J. Fauske, NDSU)


Larva (Figure 12): Black to pale gray body with markings (spots or stripes), about 1½ inches long when mature.

Adult (Figure 13): Dark gray, brown or dull yellow or tan moths with dark wing markings, robust body, wingspan of 1¼ to 1½ inches.

dingy cutwood larva
Figure 12. Dingy cutworm larva. (J. Gavloski, Manitoba Agriculture, Food and Rural Initiatives)
dingy cutwood adult
Figure 13. Dingy cutwood adult. (J. Gavlowki, Manitoba Agriculture, Food and Rural Initiatives)

Seed Corn Maggot

Larva (Figure 14): Maggot-like, about ¼ inch long, cylindrical, legless, pale yellow-white and sharply pointed at the head end with small black mouth hooks. Found in hollowed-out seed, burrowing in emerging stem and cotyledon leaves. Larvae kill seedlings, preventing bean emergence (Figure 15).

Adult (Figure 16): Grayish-brown fly, about ¼ inch long.

seed corn maggot larva
Figure 14. Seed corn maggot larva. (W. Cranshaw, Colorado State University, Bugwood.org)
seed corn maggot damage to dry bean row
Figure 15. Damage to dry bean row from seed corn maggot. (J. Knodel, NDSU)
seed corn maggot
Figure 16. Seed corn maggot adult. (Pest and Diseases Image Library, Bugwood.org)

Spider Mite

Immature: Similar to adult, but smaller with six to eight legs.

Adult (Figure 17): Very small, less than 0.02 inch (magnification is needed to see them in detail), green, yellow or orange body, two dark spots on the abdomens for two-spotted spider mite, eight legs. Located on the underside of leaves. Produce spiderlike webbing (Figure 18) and stippling on leaves (Figure 19).

two-spotted spider mite
Figure 17. Two-spotted spider mite. (P. Beauzay, NDSU)
webbing from two-spotted spider mites
Figure 18. Webbing from two-spotted spider mites. (D. Cappaert, Michigan State University, Bugwood.org)
stippling injury from two-spotted spider mites
Figure 19. Stippling injury from two-spotted spider mites. (J. Knodel, NDSU)

Printing support was received from the Northarvest Bean Growers Association and the U.S. Department of Agriculture’s National Institute of Food and Agriculture, Crop Protection and Pest Management Program grant no. 2017-70006-27144
