Is Your Playground Safe for Kids?

In a survey conducted in 2004, U.S. playgrounds received a grade of C+ on overall safety, according to a study done by the University of Northern Iowa.

• About four out of five playground-related injuries occur on public playgrounds. One out of five injuries occur on home playgrounds. On average, 15 children die each year as a result of these accidents.
• The majority of playground injuries (about 63%) are equipment-related.
• About 80% of public playgrounds have some kind of protective surfacing, but only 9% of home playgrounds have protective surfacing.

Source: Consumer Product Safety Commission, www.cpsc.gov

• Children ages 5 to 9 account for more than half of all playground-related injuries.
• Children age 4 and under are more likely to suffer injuries to the head and face.
• Children ages 5 to 14 are more likely to suffer hand and arm injuries.
• Young children are at higher risk for injury when playing on age-inappropriate equipment. Children under 5 should have a separate, age-appropriate play area.
• Children who fall on concrete or asphalt are more than twice as likely to be injured, compared with children who fall on shock-absorbing material.

Source: Safe Kids USA, www.safekids.org

The material used under and around playground equipment can influence the outcome of a fall greatly.

• Asphalt and concrete are not acceptable for use as playground surfaces because they have no shock-absorbing abilities.
• Grass, found under many swing sets and home play areas, should not be used as a protective surface. Weather and wear can reduce its shock-absorbing abilities greatly.
• Loose-fill materials, such as sand, pea gravel, wood chips and shredded tires, have adequate shock-absorbing qualities with proper depths and maintenance. (See Table 1)
• Poured rubber or rubber mats require minimal upkeep after installation to maintain shock-absorption quality.

Advantages and disadvantages are associated with all surface materials. No material will prevent all injuries.

Table 1. Minimum compressed loose-fill surfacing depths.

Source: Consumer Product Safety Commission, www.cpsc.gov

Photo Credit:

iStock.com

The ASTM, originally known as the American Society for Testing and Materials, is an international standards organization. It has set requirements that playground surfaces must meet to be considered safe.

The testing takes note of a variety of factors:

• Material used
• Depth of material
• “G-max”
• HIC (Head Injury Criterion)

The G-max and HIC values help evaluate the shock-absorbing ability of the surfacing material and allow for comparison.

With these values, a critical height is determined. Remember that these numbers are simply estimates. The exact impact threshold for a head injury cannot be determined due to individual and situational differences.

The most common method of testing the shock-absorbing capacity of playground surfaces is to drop a metal form (shaped like a head) from various heights on playground equipment onto the material being tested. For more information, visit the ASTM Web site at www.astm.org.

1. A point from which a child could fall is chosen and the height is measured.
2. The depth of the protective surfacing material under the drop point is measured.
3. The head form is dropped. It senses the impact and reads back the G-max and HIC values.
4. This procedure is repeated from different heights on various pieces of playground equipment.

According to a study of 19 North Dakota playgrounds, most did not meet the safety requirements for surfacing. Only two of the 19 areas tested had the recommended 12 inches of loose fill. Forty-two drop points were tested on 19 different playgrounds. Nearly 55% of them did not meet the standards set by the ASTM. Table 2 provides some of the data from the study.

Table 2. Results from selected playgrounds in North Dakota using ASTM standards.

Source: Research presented by T. Barnhart, Ph.D., Professor, NDSU, at 2008 ACA Camp Research Symposium, Nashville, Tenn.

* To meet ASTM standards, the G-max must be under 200 and the HIC value less than 1,000. If these standards are met, a life-threatening head injury is not likely to occur due to a fall.

Regular maintenance is required for all playground equipment, including the protective surfacing on the playground.

Loose-fill surfaces are displaced easily with use.

The solution for this safety issue is simply to move the fill that has been pushed to the edges back to the center around the equipment. More fill may need to be added to restore appropriate depths.

More than 240,000 children in the U.S. visit the emergency room with playground-related injuries each year.


Photo Credit:

iStock.com

The Consumer Product Safety Commission (CPSC) recommends a minimum of 12 inches of loose-fill surfacing under and around public playground equipment to reduce the risk of potentially life-threatening injuries from falls.

Home playgrounds should have an initial fill level of 12 inches.

Due to wear, some compression will occur.

Levels should be maintained at a minimum of 9 inches.

Playground safety involves much more than just proper surfacing.

This list of questions was adapted from the Consumer Product Safety Commission:

Source: www.cpsc.gov

For more information on this and other topics, see www.ndsu.edu/extension
